DSX5000, Square Drive Aluminum Hydraulic Torque Wrench, 5,635 ft. lbs. Torque, 1 1/2 in. Square Drive

Safety and Performance

• Fully enclosed drive for maximum safety
• Fine-tooth ratchet prevents the tool 'locking on'
• Built-in, work-at-height safety tether connection
• Patented, easy-to-use, quick release, retained reaction arm
• High-strength, lightweight aluminum, slimline design suited for complete operator safety
• Retained quick release push-button
• 35° rotation angle and rapid return stroke for fast operation
• High-cycle design with fewer moving parts making it a more efficient tool to operate, maintain, or repair

ATEX certified

• All DSX tools are CE - ATEX certified

Accuracy

• Constant torque outputs with an accuracy of +/- 3%

Simplicity

• Robust handle which mounts on either side of the tool for extra maneuverability and safer operation
• Push-button square drive and reaction arm for fast changes and adjustments
• Easily accessible work-at-height connection point

Torque Wrench

• Material type: Aluminum
• Maximum Torque Output: 5635 ft lbs | 7640 Nm
• Square Drivein: 1.5
• Minimum Torque: 563 ft lbs | 764 Nm
• Nominal Torque: 5635 ft lbs | 7640 Nm

Dimensions

• Dimension B: 4.4 In | 112 Mm
• Dimension G: 7.1 In | 180 Mm
• Dimension A: 2.7 In | 69 Mm
• Dimension F: 1.5 In | 38 Mm
• Dimension E: 7.6 In | 192 Mm
• Dimension D: 5.8 In | 148 Mm
• Dimension H: 10.2 In | 260 Mm
• Dimension C: 6.8 In | 173 Mm

Specifications

• News Feed Product Group: Torque Wrenches, Torque Wrench Pumps
• Sub Types: Square Drive Torque Wrench
• Shipping Weight: 17.82 lbs
• Product Line: Bolting Tools
• Bundle Product Ids: ENPD01,DSX5000-08,DSX5000-SA02,SWH6A
• Weight: 17.9 lbs | 8,1 kgs
• Type: Torque Wrench
