E290PLUS, Manual Torque Multiplier, Reaction Bar, 750 ft. lbs Torque, 3/4 in. Square Drive

Features

• Most models operator protected by anti-backlash device
• Reaction bar or reaction plate type
• High efficiency planetary gear sets achieve high output torque from low input torque
• Multiplier output accuracy ± 5% of input torque
• Reversible, tighten or loosen bolts

Specifications

• Upsell item: E291,E391,E392,E393,E492,E493,E494,E495,PTW1000C
• Product Line: Bolting Tools
• Height: 3.3 in | 84 mm
• Shipping Weight: 14.2 lbs
• Width: 2.8 in | 71 mm
• News Feed Product Group: Multipliers, Torque Wrenches
• Type: Torque Wrench
• Weight: 4 lbs | 1.8 kgs
• Sub Types: Reaction Bar Multiplier
• Country of Origin: United States

Torque Wrench

• Torque Ratio: 3,3 : 1
• input Torque: 309 Nm | 227 ft lbs
• Maximum Torque Output: 750 ft lbs | 1020 Nm
• Overload Protection: No
• Anti Backlash: No
• Dimension L: 8.6 in | 217 mm

Dimensions

• Dimension H: 3.3 In
• Dimension D: 71 Mm
