G4039L, Hydraulic Pressure Gauge, 4.0 in. Face, Lower Mount, Glycerine Filled, 10,000 maximum psi

Features

• Gauge snubbers or needle valves recommended for high cycle applications
• Calibrated in dual scale reading in psi and bar
• All pressure sensing parts sealed and dampened by glycerine for long life
• Includes safety blow-out disk and pressure equalizing membrane

Gauge

• Minor Graduationbar: 10
• Threadin: 1/2 NPTF
• Minor Graduationpsi: 100
• Style: Glycerine Filled
• Major Graduationpsi: 1000
• Major Graduationbar: 100
• Mount: Lower Mount
• Face Diameter: 100 mm
• Accuracy Percentageof Full Scale: 1

Dimensions

• Dimension A: 4 In | 100 Mm
• Dimension B: 1.93 In | 49 Mm
• Dimension D: 5.38 In | 136 Mm
• Dimension C: 1/2 nptf In | 1/2 NPTF Mm

Specifications

• Country of Origin: China
• Type: Gauge
• Product Line: Industrial Tools
• News Feed Product Group: Gauges, Pumps
• Shipping Weight: 1.9 lbs
• Sub Types: Pressure Gauge
